DC BIAS CONDENSOR
Elevate your sound quality to the next level. The S-Mic 3 delivers superior audio reproduction, capturing every nuance with precision. From the deepest lows to the crispest highs, the S-Mic 3 covers the full spectrum with its 50Hz to 20kHz frequency response range.
And with a sound pressure level of 130dB, the S-Mic 3 can handle even the loudest environments, ensuring distortion-free recordings.
SUPERCARDIOID PICKUP PATTERN
Minimize unwanted background noise with a remarkable -18dB off-axis suppression, keeping your audio focused on what matters most. Enjoy a smooth tone and minimal off-axis coloration, allowing you to capture sound with true fidelity and authenticity.
With its high sensitivity, the S-Mic 3 requires less gain, reducing the risk of distortion and ensuring your audio maintains its pristine quality. Furthermore, the S-Mic 3 boasts a remarkable 12dB noise floor (A-weighted) for pristine audio in every recording.
ULTRA-LIGHTWEIGHT DESIGN
The S-Mic 3 is 60% lighter than our previous long shotgun.
Crafted from durable aluminum alloy, the S-Mic 3 weighs a mere 80g, making it easy to handle and mount without adding unnecessary bulk to your equipment. The S-Mic 3's body was also designed to suppress radio frequency interference, ensuring clear audio.
MOISTURE RESISTANT DESIGN
Conquer humid shooting locations with confidence. The S-Mic 3 is engineered to withstand moisture, ensuring your audio remains crystal clear even in challenging environments.
SPECIFICATIONS
Sound Field | Mono |
Transducer | Condenser |
Polar Pattern | Supercardioid |
Frequency Range | 50Hz ~ 20kHz |
Equivalent Noise Level | 12 dB A-Weighted |
Max SPL | 130 dB SPL |
Off Axis Rejection | 6 dB at 60° 14 dB at 120° >18 dB at 180° |
THD | < 0.5% |
Load Impedance | 800 Ohms |
Sensitivity | -32±2dB re 1V/PA @ 1 kHz |
Output Connector | 3-Pin XLR |
Operating Current Consumption | 1.5mA |
Operating Voltage | P 24V or P 48V |
Operating Temperature | 14 to 158°F / -10.00 to 70.00°C |
Length | 9.84″ / 250 mm |
Diameter | 0.75″ / 19 mm |
Weight | 0.17 lbs / 80g |
Material | Aluminum |
